Heat Exchangers
Welling and Crossley Heat Exchangers available to fit engines from 30KW to 1200KW. Perfect for use on engines for Fire, industrial or irrigation applications.
Category: Fire Control Panels
Available to fit engines ranging from 30 kW to 1200 kW.
CONSTRUCTION
- Marine grade cast aluminium with header tank and 7 psi pressure cap
- Tube stack 90 / 10 copper nickel
- End caps bronze
- Sealing “O” Ring
| Models Available | Output Rating |
Dimensions LxWxH |
Mass Kg |
| Heat Ex 200 CH
Heat Ex 300 CH Heat Ex 400 CH Heat Ex 700 CH Heat Ex 800 CH Heat Ex PH 300 |
30 kW
100 kW 200 kW 250 kW 600 kW 1200 kW |
300 x 95 x 310 mm
596 x 179 x 293 mm 716 x 179 x 306 mm 851 x 179 x 331 mm 1050 x 223 x 406 mm 1100 x 290 x 580 mm |
7.2 kg
27.5 kg 32 kg 40 kg 68 kg 128 kg |
