245kW at 2400 RPM Crossley Diesel Fire Engine – Radiator Cooled

Model No.: 6126Ti-1-RAD-FIRE-13

Crossley diesel air radiator cooled diesel engine’s are specially designed in Australia to fully comply with the strict Australian fire engine standards AS 2941-2013. These engines undergo stringent testing to ensure quality performance and reliability. They pair perfectly with our Diesel Fire Pump Controller.

Call us on 1300 656 276
Stock Number: 6126Ti-1-RAD-FIRE-13 Categories: ,

Power Rating: 245 kW
Engine Model: Crossley Diesel Engine
Starter Voltage: 24 V
Cylinder No.: 6 Turbocharged & Int
Cubic Capacity: 9.73 L
max. speed: 2400 rpm
Flywheel Housing: 1 SAE
Flywheel: 14 SAE
Combustion Air Flow: 294 L/sec
Heat Rejection to Coolant: 196 kW
Heat Rejection to Atmosphere: 37 kW
Radiator Fan Air Flow: 750 m3/min
Exhaust Gas Flow: 872 L/sec
Exhaust Gas Temperature: 585 °C
Exhaust Pipe Size: 5″”
Governing: Mechanical
Approx. Fuel Consumption @ Full Load: 60 L/hr
Weight: 1280 kg

*Specifications are subject to change without notice
  • Air radiator cooling
  • Engine feet
  • Energise to stop solenoid fitted
  • Speed transducer fitted
  • Condensation trap below exhaust manifold
  • Guards fitted to suit 2013 specifications
  • Exhaust flex muffler (supplied loose)
  • Jacket heater with additional dry contact for remote indicator (if applicable)
  • fuel lines to suit 2013 specifications
  • oil pressure sender fitted
  • Engine water temp sender fitted

** This engine fully complies with the Australian Standard AS2941-2013
