223kW at 2200 RPM Doosan Diesel Engine – Heat Exchanger
Model No.: P086Ti-HX-FIRE-13
Doosan Heat exchanger cooled diesel engine have mechanical fuel injection for easy maintenance and servicing. These engines fully comply with the strict Australian fire engine standards AS 2941-2013. They undergo stringent testing to ensure quality performance and reliability and pair perfectly with our Diesel Fire Pump Controller.
Power Rating: 223 kW
Engine Model: DOOSAN
Starter Voltage: 24 V
Cylinder No.: 6
Cubic Capacity: 8.07 L
max. speed: 2200 rpm
Flywheel Housing: 1 SAE
Flywheel: 11.5 SAE
Combustion Air Flow: 386 L/sec
Heat Rejection to Coolant: 158 kW
Heat Rejection to Atmosphere: 15.6 kW
Exhaust Gas Flow: 788 L/sec
Exhaust Gas Temperature: 510 °C
Exhaust Pipe Size: 4″”
Min. Secondary Cooling Water Flow: 3 L/sec @ 20°C
Governing: Electronic
Approx. Fuel Consumption @ Full Load: 53.52 L/hr
Weight: 1250 kg
*Specifications are subject to change without notice
- Heat exchanger cooling
- Engine feet
- Energise to stop solenoid fitted
- Speed transducer fitted
- Condensation trap below exhaust manifold
- Guards fitted to suit 2013 specifications
- Exhaust flex muffler (supplied loose)
- Jacket heater with additional dry contact for remote indicator (if applicable)
- fuel lines to suit 2013 specifications
- oil pressure sender fitted
- Engine water temp sender fitted
** This engine fully complies with the Australian Standard AS2941-2013
